On the whole,UVThe printer can be mainly divided into two parts of the external structure and the internal structure, and there are four core components, such as the nozzle, the board card, the servo motor, and the rack design work together to form a powerful and stable effectUVA flatbed printer.
External structure:It includes the external trolley head, guide rail, grating, belt, ink path system and control panel.
Internal structure:Including circuit board, controller, software control, power cord, motor and other electronic accessories.
Core component one: nozzle
UVThe printer nozzle is the decisive factor for normal printing work, and it is necessary to clean the ink and moisturizing nozzle in time after use to ensure that the nozzle is in good conditionPrint status. The nozzle has a great impact on the indoor environmental conditions, and the surrounding temperature is not required to exceed35Degree, humidity is not lower than20%Not more than60%,Avoid static electricity generated by drying, wet water in the printing medium resulting in poor printing effect, or serious wearUVPrinter head.
CoreComponent 2: Board card
Act asUVThe board card of the printer's core electronic accessories has the function of control system and stability performance. In daily useDo not drop ink or liquid into the board, and install the corresponding ground wire to avoid short-circuit burning. Some brandsUVThe printer will have a board cardIf the dongle is found, it should be removed immediately to avoid the high cost of later upgrade and maintenance.
Core component three: servo motor
Servo motor forUVPrinter printing provides sufficient power and is a key factor affecting printing length and accuracy. In choosingUVWhen printing, carefullyviewUVBasic parameters of the printer, choose imported high-quality motor brands, such as AudleyUVThe printer adopts imported double servo motor, fast speed and stable performance.
Core component four: Rack design
Rack design includes many aspects such asUVThe appearance design of the printer, metal frame, suction platform, etcUVPrinter lasting printing escort. AudleyUVThe printer uses one frame, two sidesUVCuring lamp,350WVacuum adsorption platform, error between materials can beto3mmMore durable, stable and efficient print output.
High speed sprinkler :I3200 high speed sprinkler, compatibility: weak solvent, water, thermal sublimation, UV Dual-head configuration: true high-speed printing, 75 square per hour; Control system: the most stable domestic board control system; Silent linear guide: imported silent linear guide, more stable machine movement 1 longer service life; Anti-scratch device: prevent the material from lifting the scratch nozzle, effectively protect the nozzle; Intelligent heating: Dual infrared heating: reduce drying time, speed up paper delivery efficiency, ensure high-speed printing; New frame design: mold appearance new aluminum alloy body structure design, effectively improve the picture printing quality; The height of the trolley frame adjustment: according to the thickness of the material, adjust the height of the nozzle, convenient for users to use more media; Silent linear guide: imported silent linear guide, more stable machine movement, longer service life;
1.With Epsoni3200-A1/E1Original authentic sprinkler head 2.Imported silent linear guide rail: no noise, more stable movement, more stable printing, extend the service life of the machine. 3.All aluminum lifting ink stack: automatic lifting ink stack, tighter sealing and long-term moisturizing, automatic cleaning Settings, cleaner and simpler printing. 4.German Igus chain, the movement is silent more stable. 5.Three speed adjustable press wheel, prevent static electricity does not fly ink, printing size is more accurate, no wrinkles.
With Epsoni3200-U1Nozzle, four-head configuration, high precision mode can be reached32㎡/h, production mode48㎡/h. Platform three zones adjustable suction, high power water coolingUVLights. Head automatic height measurement, anti-collision protection, nozzle independent constant temperature system. Heavy-duty pneumatic expansion shaft, rolling simple discharge system, large bearing weight, long service life, uniform retracting and discharging materials.
