The banner machine is the same as our other machines and equipment, it also has its own operating specifications and operational precautions, we need to follow the operating steps to use, otherwise it is easy to cause machine failure. So what should you pay attention to when working with a banner machine? Let's listen to the share of Indu Xiaobian!
Machine use precautions
② Before starting:
2.The working input voltage isAC 220VToo high or too low voltage will cause the equipment to work abnormally, and AC must be used220V 2KWPower regulator.
3.Check whether the water tank is short of water, whether the pump is running normally, and the water level at least reaches one-third of the capacity of the water tank when working.
4.Carefully check whether the print head water pipe interface leaks, and confirm that there is no water on the overall surface of the print head. When the rubber roller is dry and free of foreign matter, it can be started.
③ In order to prevent the printing head from overheating and shortening its service life, it is recommended to print continuously100At about a meter, Machine stop5-10In a minute, Continue to work after the print head cools. Continuous machine operation10After an hour, Should be suspended2Hours, huge high load operation is also easy to cause machine damage.
④ Print travel accumulated to800Metre or2-3When rolling the cloth, use a cotton swab to gently wipe the print head with anhydrous alcohol. Do not use a wet paper towel or other hard objects to wipe the print head.
Note during printing:
1.If it is found that the data line falls off accidentally during the working process of the machine, the power supply must be cut off immediately, and the sowing can be done after confirmation; (If inserted incorrectly or incorrectly, it will burn the print head and motherboard)
2.Print hair hot plate and print head surface should be kept clean, no foreign matter.
3.Ensure that the printing medium is clean and free of foreign matter before it can work normally.
4.To prevent static electricity on the print headIC.When the heating plate is damaged, do not touch the terminal directly with your hand and do not let the terminal contact live matter.
5.Observe the water tank at any time, pay attention to add water at any time.
6.Do not plug and unplug data cables and print cables.
⑤ The machine is placed in a dry and ventilated place to ensure that the working environment of the machine is clean and sanitary. No dust; When the machine is not used for a long time, it is necessary to take measures to prevent dust and moisture, and do not place liquid on the chassis.
⑥ Need to be
⑦ Non-professionals are not allowed to debug the machine at will, so as not to affect the normal work.(In case of failure or replacement of parts, please contact your local agent for professional maintenance.)
⑧ Ribbon storage:In order to ensure the printing effect, please5℃to40℃, 20% to85%Storage under temperature conditions, storage time cannot exceed1This year. It is strictly forbidden to expose the ribbon directly to sunlight or damp environment.
note:Full load printing is strictly prohibited(Full plate printing)In this state, the print head will be seriously damaged and the print head life will be greatly shortened.
High speed sprinkler :I3200 high speed sprinkler, compatibility: weak solvent, water, thermal sublimation, UV Dual-head configuration: true high-speed printing, 75 square per hour; Control system: the most stable domestic board control system; Silent linear guide: imported silent linear guide, more stable machine movement 1 longer service life; Anti-scratch device: prevent the material from lifting the scratch nozzle, effectively protect the nozzle; Intelligent heating: Dual infrared heating: reduce drying time, speed up paper delivery efficiency, ensure high-speed printing; New frame design: mold appearance new aluminum alloy body structure design, effectively improve the picture printing quality; The height of the trolley frame adjustment: according to the thickness of the material, adjust the height of the nozzle, convenient for users to use more media; Silent linear guide: imported silent linear guide, more stable machine movement, longer service life;
1.With Epsoni3200-A1/E1Original authentic sprinkler head 2.Imported silent linear guide rail: no noise, more stable movement, more stable printing, extend the service life of the machine. 3.All aluminum lifting ink stack: automatic lifting ink stack, tighter sealing and long-term moisturizing, automatic cleaning Settings, cleaner and simpler printing. 4.German Igus chain, the movement is silent more stable. 5.Three speed adjustable press wheel, prevent static electricity does not fly ink, printing size is more accurate, no wrinkles.
With Epsoni3200-U1Nozzle, four-head configuration, high precision mode can be reached32㎡/h, production mode48㎡/h. Platform three zones adjustable suction, high power water coolingUVLights. Head automatic height measurement, anti-collision protection, nozzle independent constant temperature system. Heavy-duty pneumatic expansion shaft, rolling simple discharge system, large bearing weight, long service life, uniform retracting and discharging materials.
