Among the many printing devices,Piezoelectric photo machineThis main advertising inkjet printing equipment is no stranger to us, the rich graphic and image content is inseparable from the high-precision printing output of the photo machine, and the special creativity of the advertising screen is highlighted with gorgeous colors.
Photo machine plays a big role in advertising printing, of which the main credit is attributed to large and small accessories, the small role plays an important role in the photo machine. Below we simply share some of the common accessories in the photo machine its name and use.
Photo machine in our common accessories such as nozzle, ink cartridge, ink pad, ink stack, ink sac, scraper, motor, copper sleeve, etc., these are photo machine we often use and see the accessories, many photo machine failures are easy to occur on these small accessories, as long as we are familiar with it to understand their functions and effects, In the photo machine printing problems we can easily find the cause and solve.
1.Nozzle, nozzle is a very important accessory in the photo machine, the quality of the nozzle directly affects the print output of the photo machine, the print quality of the nozzle also directly affects the color effect of the printout image and the clarity of the image, most of the piezoelectric photo machine is the use of Epson piezoelectric nozzle, such as Epson fifth generation nozzle and so on, Epson piezoelectric nozzle, Long service life, high printing accuracy, fast speed, more stable use, in the Zhengzhou Odley series of piezoelectric photo machine, Epson fifth generation, seven generation of piezoelectric nozzle, divided into a single nozzle photo machine and double nozzle photo machine.
2.The beam and high-quality Audley photo machine are made of linear rail splicing surface and paper holder assembling surface, which are processed by high precision CNC milling machine.
3.The end of the shaft of the Audley photo machine is designed with a bearing bracket, which avoids the formation of cantilever beams and allows the material to be deformed during printing while maintaining high accuracy;In addition, the runout error is always controlled at0.03mmWithin, the height error is0.1mmInside, cooperate with high-precision paper holder to complete precision printing.
4.The paper pressing assembly, wherein the paper pressing frame is made of abrasive stamping, and the accuracy error does not exceed0.03mmPress the paper small wheels in a straight line, concentricity error in0.08mmWithin, internal control concentric error does not exceed0.02mmSuper wear-resistant material, soft outside and hard inside, large friction coefficient, to ensure smooth and smooth paper, effectively avoid deviation or indentation, can be applied to a variety of smooth materials printing work.
5.Guide rail, high quality Audley photo machine used in TaiwanHIWINGuide rail, equipped with high-precision ultra-silent double sliders, to ensure the stability of the car moving the slider and the paper holder assembly surface parallel0.05mmWithin, greatly improve the printing accuracy.
6.The printing platform of the high quality Audley photo machine is machined by a high precision CNC milling machine, and the flatness error is insufficient0.07mmThe parallel error between the linear guide rail and the printing platform is also in0.02mmWithin.
7.The motor and motor are the main power supply core of the photo machine, such as the paper motor, which controls the printing paper, paper feed and paper return of the photo machine;The back and forth movement of the nozzle trolley frame of the photo machine is also powered by the motor. The quality of the motor also directly affects the related operation of the photo machine, such as the photo machine bracket overcurrent, excessive resistance and so on.
8.Ink bottle, ink cartridge is to provide continuous ink supply for the photo machine, four groups of colors, respectively, ink blue, yellow and red four colors.
9.Ink bag, ink bag is generally located above the photo machine nozzle, connected between the nozzle and the ink tube, ink bag has a filter screen, it can filter out the impurities in the ink, ensure the smooth ink supply, prevent the nozzle blockage, broken line and other faults, play the ink filtration role.
10.Gears, motors. The new generation of high-quality Audley gear adopts an integrated design with high precision, good rigidity, strong stability and long life;The motor is a high-performance brushless motor, known for its fast speed, high precision and long life, and is more suitable for long-term printing work.
11.The whole structure of the frame and high-quality Audley photo machine has been improved, increasing the thickness of the body sheet metal, more stable, and improving the smooth printing.
12.Board cards,100MNetwork card printer interface, simple operation, users do not have to install the driver can also achieve high-speed, stable printing effect, the machine supports multi-computer printing business, compatibleWIN732Bit,64Bit operating system;The thoroughly encrypted and decrypted board is combined with Epson's fifth generation nozzle for strong stability.
12.The scraper, which plays the role of cleaning the surface of the nozzle in the photo machine, is generally installed below the nozzle of the photo machine and on the left side of the ink stack. If the photo machine scraper is damaged, it is easy to cause the photo machine to break ink and other phenomena.
14.The trolley and high-quality trolley frame can be adjusted by the knob according to the actual situation of the user, which is very suitable for printing media of different thickness. The split ink sac assembly provides convenience and easy maintenance for later maintenance.
15.The three-stage heating system and the three-stage heater can be controlled separately to heat the consumables to the appropriate temperature and improve the ink absorption of the consumables;The front heating reduces the drying time, which can speed up the paper receiving efficiency and ensure the smooth printing of high-speed paper.
Audley full series of piezoelectric photo machine, using the brand of Leisai motor application, precision is more accurate, more powerful, while greatly improving the service life of the motor, more effective to maintain the photo long time uninterrupted print output, to ensure the stable use of the photo machine.
High speed sprinkler :I3200 high speed sprinkler, compatibility: weak solvent, water, thermal sublimation, UV Dual-head configuration: true high-speed printing, 75 square per hour; Control system: the most stable domestic board control system; Silent linear guide: imported silent linear guide, more stable machine movement 1 longer service life; Anti-scratch device: prevent the material from lifting the scratch nozzle, effectively protect the nozzle; Intelligent heating: Dual infrared heating: reduce drying time, speed up paper delivery efficiency, ensure high-speed printing; New frame design: mold appearance new aluminum alloy body structure design, effectively improve the picture printing quality; The height of the trolley frame adjustment: according to the thickness of the material, adjust the height of the nozzle, convenient for users to use more media; Silent linear guide: imported silent linear guide, more stable machine movement, longer service life;
1.With Epsoni3200-A1/E1Original authentic sprinkler head 2.Imported silent linear guide rail: no noise, more stable movement, more stable printing, extend the service life of the machine. 3.All aluminum lifting ink stack: automatic lifting ink stack, tighter sealing and long-term moisturizing, automatic cleaning Settings, cleaner and simpler printing. 4.German Igus chain, the movement is silent more stable. 5.Three speed adjustable press wheel, prevent static electricity does not fly ink, printing size is more accurate, no wrinkles.
With Epsoni3200-U1Nozzle, four-head configuration, high precision mode can be reached32㎡/h, production mode48㎡/h. Platform three zones adjustable suction, high power water coolingUVLights. Head automatic height measurement, anti-collision protection, nozzle independent constant temperature system. Heavy-duty pneumatic expansion shaft, rolling simple discharge system, large bearing weight, long service life, uniform retracting and discharging materials.
