UV DTF:
UV DTF printer, also called roll to roll printer, is an efficient commercial printer that can be customized, such as stickers, labels, barcodes, packaging boxes, packaging bags, labels, etc., through continuous and automatic AB film, it can achieve instant printing Ready-to-use, waterproof and wear-resistant, colorful, vivid and clear personalized products.
You just need to cut the printed film and paste it where you want to paste it.
Product details:
Product Parameters:
| A3 UV DTF Printer | ||
| 1 | Model | 30cm UV DTF |
| 2 | Print Head | XP600*3 |
| 3 | Printer Width | 300mm |
| 4 | Resolution | 1080dpi |
| 5 | Color | C/M/Y/K/LC/LM+W+Varnish |
| 6 | Ink | UV ink |
| 7 | RIP Software | Photo print |
| 8 | Power Supply | 220V 50HZ/60HZ |
| 9 | Speed | 6pass:3m2/h 8pass:2m2/h |
| 10 | Opcration Environment | Temperature:20-30°C humidity: 40RH-60RH |
| 11 | Power Consume | 1200w |
| 12 | Warranty | One Year(not Include Head And Ink System) |
| 13 | Ink Supply System | CISS Continuously Ink Supply System |
| 14 | Dismension | 1200*500*1160mm |
| 15 | Net /Gross Weight | 100kg/130kg |
| 16 | Package Size | 1520*730*750mm |
Main Features:
- High precision rubber roller, intelligent temperature control rubber roller heating
- Equipped with paper-out alarm sensor function
- Intelligent tension bar collecting waste film.
- The high-precision all-aluminum main body and high-precision platform supportconfiguration, providing high resolution printing support for high-quality printouts.
Production Application:
Double use print on a film then transfer(UV printing) or print directly on objects(UV printing)
Suitable for printing on both rigid and flexible material, such as phone cases,metal, wood,tablet cover,PVC,glass,paper,ceramic tiles,lether.etc.also avaiable in 3D textured and raised printing.
For cylindrical objects,such as bottles,mugs,a rotary platen is required.
