产品名称

S7000-X5 Dual X5 Head Eco Solvent

没有此类产品
Page view
产品描述



Features & Parameters:



1) With Dual Epson X5 print head, resolution 1440DPI.



2) 6 color C/M/Y/K/LC/LM printing, CISS ink supply system.



3) Hiwin leadrail made in Taiwan,more stable movement of carriage, without sliding noise .



4) Equiped with front and back heating stytem,controled individual.



5) Equiped with platform sucking fans strongly. Dry fans customers optional.



6) Automatic feeding system for roll materials which width max 1.8/1.6m.



Model S7000-X5
Printhead Dual EPSON X5 Piezo-Electric Prinhead
Number of Printhead Dual
Print Resolution 1440dpi
Maximum Print Width 1850mm
Print Speed Draft Model 2pass:30m2/h
Production Model 3pass:20m2/h
Quality Model 4pass:16m2/h
High-resolution Model 5pass:10m2/h
Ink Type Dye Ink, Pigment ink, Sublimation Ink
Color Double 6 colors(K\C\M\Y\Lc\Lm)
Capacity 450ml of each ink cartridge
Ink Supply System Negative Pressure Continuous Ink Supply System
Media Maximum Width 1550/1850mm
Feeding System Maximum Weigh 55kg
Take up System Optional
Type

Indoor PP,PP sticker, Photo paper, Backlit film,

PVC film,etc.

Printhead Height Adjustable
Printhead Clean Automatically Cleaning,Owning Anti-blocking, Auto flash & Moisturizing function
Driver System Leadshine810 High Accuracy Driver
Heating System Tri-stage Heating System Control By PID Temperature Control System
Drying System External Drying Fan (Optional)
Language Chinese\English
Operation System WindowsXP\Win7 32 bit\Win7 64 bit
Print Interface 100M/Network Interface
Compatibility Support LAN Print
RIP Software MainTop 5.3\photoPRINT
Working Enviroment Temperature:18°- 35° Humidity:35RH - 65RH
Power Supply AC_110V/220V, 50/60HZ
Power(W) Stand-by Power 32W,Maximum Power 1500W
Noise Stand-by<32dB ,Working<65dB
Package Dimension 2900/3100mmx800mmx770mm(LxWxH)
Package Weight

285/320kg
